0-207 BAR / 0-3000 PSI, DIGITAL PRESSURE GAUGE, 1/4" NPT

PG SKU: DPG222 https://odoo.pgflowteknik.dk/web/image/product.template/25132/image_1920?unique=2e39a2d

  • Simple 2 button operation
  • Reset to zero feature
  • Backlight turns on when on/off button is pressed
  • Option for display to remain continuously on
  • Continuous Peak pressure indication option
  • 316L welded diaphragm seal
  • Rubber boot is standard
  • ASME B40.100 compliant
  • RoHS compliant
  • ±1% accuracy (±0.5% optional for gauges up to 10,000 psi)

Not Available For Sale

Denne kombination eksistere ikke.

Salgs- og leveringsbetingelser

Spørg på leveringstid, hvis ikke på lager

Case Size2.5″ (63mm)
Case MaterialABS
Rubber BootSilicone rubber
LCD Display2″ x 3/4″ (48mm x 16mm)
Connection1/4″ NPT 304SS
Sensor316L welded, Piezo
Operation Life1 million cycles
Power Supply2 x AAA battery (1.5V)
Battery Life2yrs (auto shut-off mode)
Power ModeAuto or manual shut-off
Display Digits

4 digits to 5,000 psi

5 digits for10,000 psi and 15,000 psi

Pressure Unit Selection

psi, mH2O, mmHg, mbar, kPa ranges ≤ 100 psi

psi, bar, kgf/cm2, MPa, atm ranges ≥ 160 psi

Response Time≤ 3 Hz display refresh rate
Proof / Burst Pressure200% / 300% FS
Operating / Storage Temperature

Operating: 14°F to 122°F (-10°C to 50°C)

Storage: -4°F to 167°F (-20°C to 75°C)

Accuracy±1% (±0.5% optional for gauges up to 10,000 psi)
Enclosure RatingIP60
